International Ozone TZ-1 Ozone Generator
International Ozone TZ-1 Brochure
Total Zone / Ultra V ozone generators are the most modern, technically advanced systems on the market today. The Total Zone / Ultra V series of ozone generators utilize a proprietary TZUV-Chamber technology that allows them to produce high levels of ozone with the distinct advantage of being completely maintenance free. The TZUV-Chamber has an average life expectancy of 10,000+ hours of use. This equates to 8 hours per day, 5 days a week, for more than 5 years. When, if ever, the TZUV-Chamber requires replacing, it is very simple and inexpensive to do. All Total Zone / Ultra V ozone generators are designed and built for the utmost reliability in the harshest environments.
What Is Ozone & How Does It Work?
Ozone (O3) is a naturally occurring substance found in nature that we cannot live without. Ozone is an activated form 3 of oxygen (O2) with three atoms where regular oxygen has two. Ozone in the upper atmosphere filters out harmful 2 rays from the sun without which all life on earth would cease to exist. Closer to home ozone is produced by lightning in thunderstorms. I’m sure you have experienced the freshness in the air after a storm. Ozone is very unstable and has an average half life of 20 minutes, this is why ozone must be produced at the point of use and cannot be stored in a container for later use. Ozone will cast off it’s third atom onto any other organic element thereby oxidizing it or converting it to another substance. In the case of odors it will convert a foul-smelling substance into an non-odorous substance naturally with no unhealthy chemicals to buy, store or use. Once ozone has done it’s job it converts back to oxygen. Ozone will also deactivate and destroy molds, bacteria, virus, fungus, and mildew.
Size: 12 1/4" x 9" x 6"
Weight: 7 lbs. 9 oz.
Timer: 12 Hour With Hold
Generator: Patented SP-ARC (Silicate Polarized Arc), Coronoa Discharge Technology
Fan: 100 CFM, ABEC #5 Bearings
Ozone Output: 1500 Milligrams Per Hour
Primary Volts / Amps: 110 / 1
Secondary Volts / Amps: 14000 / .35 ma
Cycles: 50 / 60
Case Material: Anodized Aluminum (.060 / 14 Gauge)
Finish: Industrial Powder Coat
Warranty: One Year Parts & Labor
